2022 Latest Model Hi Target V10 Pro Land Surveying instrument Rtk Base And Rover GPS

Name: 2022 Latest Model Hi Target V10 Pro Land Surveying instrument Rtk Base And Rover GPS
Brand: Hi target
Price: 1 USD

Wholesale 2022 Latest Model Hi Target V10 Pro Land Surveying instrument Rtk Base And Rover GPS from china suppliers

Brand Name : Hi target

Model Number : V10 PRO

Certification : CE

Place of Origin : China

MOQ : 1PC

Price : Negotiable

Payment Terms : T/T, Western Union

Supply Ability : 1000pcs per year

Delivery Time : 5-8 work days

Packaging Details : With Standard Epxort Packing Ways

I/O port : USB Type-C interface, SMA interface

Size : 132mmx67mm

Built-in battery : 6800mAh

External Power Supply : Support USB port charging and external power supply

Dustproof and waterproof : IP68

Material : Metal with Aluminum plastic

Contact Now

Overview

Quick Details

Warranty:: 1 year

Place of Origin:: guangzhou

Brand Name:: Hi-target

channels:: 800

Beidou No. 3:: yes

Tilt measurement:: Within 30 °: ≤ 3cm

I/O port:: USB Type-C interface, SMA interface

Material:: The shell is made of magnesium alloy

Size:: 132mmx67mm

Weight:: ≤0.82kg

Built-in battery:: 6800mAh

Dustproof and waterproof:: IP68

External Power Supply:: Support USB port charging and external power supply

Supply Ability

Supply Ability: 7 Acre/Acres per Week

Packaging & Delivery

Port: shenzhen guangzhou

Lead Time:

Quantity(sets)	1 - 1	>1
Est. Time(days)	15	To be negotiated

Technical parameter 2022 Latest Model Hi Target V10 Pro Land Surveying instrument Rtk Base And Rover GPS

GNSS configuration	System kernel	Using multi-star system core
	Number of channels	800
	BDS	B1,B2,B3
	GPS	L1,L2,L5
	GLONASS	L1,L2
	GALILEO	E1,E5a,E5b
	SBAS	yes
	Output format	ASCII: NMEA-0183, binary code
	Positioning output frequency	1Hz~20Hz
	Differential support	CMR,RTCM2.X,RTCM3.0,RTCM3.2
	Static format support	GNS, Rinex dual format static data
	RTK positioning accuracy	Plane: ±(8+1×10-6D) mm (D is the distance between the measured points) Elevation: ±(15+1×10-6D) mm (D is the distance between the measured points)
	Static positioning accuracy	Plane: ±(2.5+0.5×10¯6D) mm (D is the distance between the measured points) Elevation: ±(5+0.5×10¯6D) mm (D is the distance between the measured points)
	DGPS positioning accuracy	Plane accuracy: ±0.25m+1ppm; Elevation accuracy: ±0.50m+1ppm
	SBAS positioning accuracy	0.5m
	Initialization time	<10 seconds
	Initialization reliability	＞99.99%
Built-in communication	network	Built-in 4G full Netcom network communication
	WiFi	802.11b/g access point and client mode, can provide WiFi hotspot service
	Bluetooth	Built-in Bluetooth
	Built-in transceiver
	Power	1W/2W/5W adjustable
	frequency band:	403MHz-473MHz
	Transmission rate	19.2kbps/9.6kbps adjustable Number of channels: 116 frequency bands adjustable
External radio	Power	功率:5W/10W/20W/30W adjustable
	frequency band:	403MHz~473MHz
	Transmission rate	19.2kbps/9.6kbps adjustable Number of channels: 116 frequency bands adjustable
User Interface	panel	Single button
	Indicator light	Satellite lights, signal lights, power lights
	Display screen	Industrial-grade OLED HD color display, capacitive touch screen
Advanced application	iPOWER smart balance technology, LBS, NFC
	Smart service	Voice broadcast, voice guidance, function self-check, DIY voice
	Remote Service	Remote upgrade, remote registration, remote data download
Electrical physical properties	battery	High capacity lithium battery 6800mAh/piece (Standard 2 pieces) with power display light, removable Single battery network mobile station continuously working for more than 10 hours
	Input voltage	DC 6~28VDC, with over-discharge protection
	size	Φ158mm×98mm
	weight	≤1.2kg (including battery)
	Power consumption	4.2W
	material	Shell is made of magnesium alloy material
Environmental characteristics	Dust and water release	P67, can resist temporary immersion under 2 meters water, completely prevent dust from entering
	Anti-fall	Resistance to natural drop of 3 meters
	Operating temperature	-40℃~75℃
Operating hand thin
System Configuration	model	iHand5.5
	operating system	Android 10
	processor	CPU: 8 core; 2.0 GHZ
	storage	2 GB RAM+16 GB ROM; T-Flash memory card, up to 128GB
	display	5.5’’, bright Outdoor Color capaci�ve touch screen (with touch pen, can be operated with gloves)
	enter	Physical full keyboard
Communication configuration	Cellular mobile	Built-in 4G full Netcom, dual card dual standby
	WiFi	802.11b/g access point and client mode, can provide WiFi hotspot service
	Bluetooth	Built-in Bluetooth
	NFC	Support NFC IGRS
	USB	USB, TypeC interface, OTG
Power performance	Built-in battery	7500 mAh internal
Power performance	Working time	14 hours
Physical properties	size	236 mm85 mm25 mm
	Weight	480g
	Operating temperature	-20℃ ~ +60℃
